General
| Max door width | 5000 mm |
|---|---|
| Max door width | 3000 mm, 3500 mm, 4000 mm, 4500 mm, 5000 mm |
| Max door height | 2250 mm |
| Max door height | 2150 mm, 2250 mm |
| Class (number of parking spaces) | No index |
| travel length sled (maximum) | 2475 mm |
| Installation length (minimum) | 3164 mm |
| Inbouwlengte (minimaal) | 3080 mm, 3140 mm, 3160 mm, 3164 mm |
| Operating temperature | -20 ... +60 °C |
| Protection degree | IP20 |
| Operating voltage | 230 Vac |
| Absorbed power at rest | 4.0 W |
| Recorded (max.) | 250W |
| Connection indicator lamp | No |
| Connection traffic light | No |
| Connection photocell | Yes |
| Part opening connection | No |
| Open the connection | Yes |
| Connection open / stop / close | No |
| Close the connection | No |
| Automatic closing (time) | No |
| Automatic closing (after passing photocell) | Yes |
| Safety list NC | No |
| Connection of the safety list optically | No |
| Connection safety list 8k2 | Yes |
| Power supply for accessories | Yes |
| Self-blocking | Yes |
| Limit switches | No |
| Programming tools available | Yes |
| Soft start and / or stop | Yes |
| Speed (max.) | 160 mm/sec |
| Lighting | Yes |
| Power | 550 N (55 daN) |
| Intensity | 40 % |
| Integrated receiver | Yes |
| Number of channels | 1 |
| Integrated antenna | Yes |
| Homelink | Yes |
| Modulation | FM |
| Antenna connection | No |
| Rolling code? | No |
| Homelink compatibel? | No |
| Radio Frequency | 868MHz |
| Radio code | Marantec Multi-Bit (40Bit) |
| Brand | Marantec |
