General
| Number of pushbuttons | 4 |
|---|---|
| Radio Frequency | 433MHz |
| Color of button | Black |
| Color of LED | Red |
| Radio code | Cardin S449 64Bit |
| Number of channels | 4 |
| Rolling code? | Yes |
| Self learning? | No |
| Homelink compatibel? | No |
| Battery type | CR2032 3V Lithium |
| Brand | Cardin |
Handheld transmitter Cardin TXC449400 with 4 channels
Hand transmitter Cardin TXC449400
TXC449400 is the 2023 update version of the older TXQ449400.
The Cardin TXC449400 is a 4-channel remote that functions on the frequency of 433MHz. This handheld transmitter uses an encrypted rolling code system for safe use; thanks to a 66-bit code, more than 72 trillion different codes are possible and each code can only be used once. This makes it impossible for others to duplicate your handheld transmitter.
This article is also known as:
Mod.S449
TXC449
TXC449 4CH
TXC449 400
TXC449 QZ4
TXC449 QZ/4
S449
S449 4CH
S449 400
S449 QZ4
S449 QZ/4
This article is the replacement for the older one:
TRQ449400
TXQ449400
This transmitter is compatible with:
TRQ449400.ALD Alldoorco:
Can only be programmed via the receiver, not from transmitter to transmitter!
TXQ449400 Heras:
Can only be programmed via the receiver, not from transmitter to transmitter!
Program the handheld transmitter:
Receiver without a display (RCQ449100/RQM449200/RSQ449200):
From transmitter to transmitter (using the hidden button)
Receiver with a display:
Only directly on the receiver. See the receiver's manual for the menu structure that must be navigated during programming.
Technical data:
Brand
Cardin
Type
TXC449400
Frequency
433MHz
Channels
4
Compatible with
- SSB-T9K4 - Code panel Cardin SSB-T9K4
- TXQPRO449-4 - Industrial remote control Cardin TXQPRO449-4 with 4 channels
- TXQPRO449-4A - Industrial remote control Cardin TXQPRO449-4A external antenna
- RCQ449ND00 - Receiver Cardin RCQ449ND00 433.92MHz
- RCQ449W00 - Receiver Cardin RCQ449W00 mini 2 channels 433 MHz
- RQM449200 - Receiver Cardin RQM449200 mini 2 channels 433 MHz
- TXQ449100 - Remote control Cardin TXQ449100 with 1 channel
- TXQ449200 - Remote control Cardin TXQ449200 with 2 channels
- TXQ4492P0 - Remote control Cardin TXQ4492P0 with 2 channels
- TXQ449300 - Remote control Cardin TXQ449300 with 3 channels
- TXQ449400 - Remote control Cardin TXQ449400 with 4 channels
- TXQ4494P0 - Remote control Cardin TXQ4494P0 with 4 channels
