Receiver Tedsen EKX2RFUP
Roller shutter control with integrated radio receiver, suitable for installation in a standard flush-mounted switch box.
This receiver is suitable for directly controlling a 230V AC tubular motor of a roller shutter. That is why it is also called a roller shutter control or roller shutter switch
Product features
The control is suitable for controlling 1 motor. The running time of the opening or closing movement may not exceed 90 seconds. 3 different radio codes of Tedsen SKX transmitters can be programmed into the memory.
Suitable for the transmitters
Tedsen Teletaster SKX transmitters
SKJ
SKX2
SKX3
SKX4
SKX22
SKX33
SKX44
SKX88
SKX1GS
SKX2GS
SKX4GS
SKX2HD
SKX4HD
SKX6HD
SKX2MD
SKX3MD
SKX4MD
SKX22MD
SKX33MD
SKX44MD
SKX2LC
SKX3LC
SKX4LC
SKX3LCD
SKX6LCD
SKX12LCD
SKX6LD
SKX12LD
SKX18ULCD
SKX50ULCD
SKX2WD
SKX4WD
SKX22WD
SKX44WD
Tedsen SunTed EKX transmitters
SKX D
SKX4HDW
SKX6HDW
SKX1GSW
SKX2GSW
SKX4GSW
SKX6LDW
SKX12LDW
SKX12M2W
SKX24M2W
SKX4SW
SKX2W
SKX4W
SKX4WD-SW
Tedsen SunTed controls
CLOCKDL
SKX Web Webbox
Supplied as standard
Receiver in plastic housing
Manual in various languages
Programming hand transmitters:
Directly programmable on the receiver. For this, see the manual of your control/drive/receiver.
Technical data control
Brand
Tedsen TeleTaster / SunTed
Radio Coding
Tedsen Teletaster SKX (433 DIP)
Switching time of relay contacts
Max 90 s.
