Universal 3-channel receiver from Tele Radio for remote control of access applications.
This receiver is suitable for controlling 3 different functions on your door: UP - STOP - DOWN. This can also be three different doors or gates that can be controlled with one contact.
Important to know:
This is the Tele Radio T20RX-03ASL which functions on 433Mhz. Only Teleradio T20 and T60 handheld transmitters on the 433Mhz frequency are compatible with this receiver. Tele Radio handheld transmitters on 869Mhz are not suitable for this receiver.
| Radio Frequency | 433MHz |
|---|---|
| IP protection class | IP 65 |
| Radio code | Teleradio Cougar T20, Teleradio Cougar T60 |
| Memory for number of transmitters | 30 |
| Housing material | ABS (Plastic) |
| Number of channels | 3 |
| Operating voltage | 12/24 V ac/dc |
| External Antenna connection | BNC Connector |
| Homelink compatibel? | No |
| Number of (relay/transistor) outputs | 3 |
| Brand | Tele Radio |
