Sommer SOMweb with SOMloq2 and Wi-Fi radio system
Centralized control of your gate and door operators.
With this system, drives can be controlled using a smartphone app or a web browser. Your data is safe because it is not stored on external servers, but literally stays in your home.
With just one SOMweb, you can control ten drives and conveniently open, close your garage doors or simply check the door condition.
The SOMweb supports voice control via Siri and Google Assistant. In addition, the SOMweb can also be controlled with Amazon Alexa via IFTTT.
ATTENTION: This SOMweb only works with drives that work with the BeNeLux radio code and NOT with the international radio code!!!
The Sommer SOMweb is provided with a Benelux region code and only works with devices that also have the same Benelux region code. The BENELUX region code is clearly visible on the article. The region code on the SOMweb is '00004'. If your existing Sommer equipment also has the Benelux region code, then this SOMweb is compatible with your installation.
Region codes
S11342-00001
International code
Due to the software registration, this product cannot be returned!
Compatible with:
SUMMER base+ (from 12/2018)
SOMMER pro+ (from 12/2018)
SUMMER tiga/tiga+ (from 01/2020)
SOMMER barriers (from 09/2020)
SOMMER RDC Vision+ (from software version 01.40 & 12/2020)
SOMMER STArteer S2 / STArter S2+ (from 12/2018)
SOMMER twist AM (from 07/2021)
SOMMER twist UG (from 07/2021)
SOMMER twist UG+ (from 07/2021)
SOMMER twist UG (from 07/2021)
The drive can only be used with a connected photocell!
THE HIGHEST SECURITY
All SOMweb data is stored on the integrated server. No user data is stored on remote servers that are vulnerable to hacker attacks due to the large amount of data. This way your data is best protected against hacker attacks. The communication between SOMweb and the drive takes place via the SOMloq2 radio system with 128-bit AES encryption. Push notifications about movements at the door and the optional video function provide even more safety out of sight.
Technical specifications
Radio Frequency:
868MHz SOMloq2.
Power Supply:
100 - 240 V ac 50-60Hz.
Temperature range:
–20 °C to +60 °C.
WiFi:
2.4GHz / IEEE 802.11b/g/n.
App system conditions:
see Appstore and Playstore for current specifications.
Additional modules:
Additional modules available for Z-wave, ZigBee & EnOcean radio systems.
Content and packaging
1x SOMweb interface
1x mains adapter 100-240V AC / 5V DC 1A
