Prevent injuries and damage by closing the door when there is still an obstacle underneath.
Optical safety device to protect against unsafe closing of the door.

An invisible beam monitors the opening under your gate. If this beam detects an obstacle, the door will immediately reverse and open completely. If the light beam is interrupted by an object under the gate, the gate will not even close.

A photocell can also be a pulse generator. When a pedestrian/car interrupts the beam, you can use it to open a door, switch on the lights, or any other automation.

A reflector prevents you from having to install a cable to the other side of the passage.

This photocell is IP65 and therefore also suitable for outdoor use. Fog and pollution can affect the operation or distance.

Delivery includes:

• 1x photocell 24V
• 1x reflector 80mm

Also known as:

• Reflex light barrier 24 V-AC-/-DC
• Reflex-Lichtschranke 24 V-AC/-DCC
• Photocell
• Photozel
• 90747

Connection:

• Conventional 4-wire
• 2 connections for power supply
• 2 connections for signal (potential-free relay changeover contact CO)
• Maximum load output: 0.5A (48Vdc) / 0.6A (50Vac)
• 1 connection as TEST input
